Choosing between GOES and NGOES is not really about which material is “better.” It is about how the magnetic field moves after the steel becomes part of the final core.

For transformer cores, the flux usually follows a stable path. That is where GOES makes sense, especially when the core design can make proper use of the rolling direction. For motors, generators, compressors, and EV traction motors, the magnetic field changes direction during operation. In those cases, NGOES is usually the more practical choice.

A high-grade electrical steel sheet can still perform badly if the magnetic direction does not match the way the device actually works.


Quick Answer

Choose GOES when the magnetic flux mainly runs in one direction, such as in transformer cores. It can offer very low core loss and high permeability, but only when the rolling direction is controlled properly.
Choose NGOES when the magnetic field rotates or changes direction, such as in motor stators, generators, alternators, and EV drive systems. It gives more balanced magnetic performance across the sheet.
The first question is not price. It is not even the grade name. It is this: What does the flux path look like in the finished part?
GOES can justify its higher cost in transformers that run for many hours and need low no-load loss. NGOES is often easier to slit, stamp, and stack for motor laminations.

What Electrical Steel Does

GOES and NGOES both belong to the electrical steel family, a group of soft magnetic steels designed to carry magnetic flux with lower energy loss. They are also commonly described as silicon steels because silicon helps increase electrical resistivity and reduce eddy-current loss.

Industry materials usually describe electrical steel as a Fe-Si soft magnetic material, with grain-oriented and non-oriented types used for different magnetic paths.

GOES: Best When the Direction Is Controlled

Grain-oriented electrical steel has a grain structure aligned with the rolling direction, allowing very low core loss and high permeability when the magnetic path follows that direction. Move away from that direction, and the advantage drops quickly.

That is why GOES should not be treated like a general-purpose magnetic sheet. During slitting, cutting, stacking, and core assembly, the rolling direction has to be kept under control. If the layout ignores that direction, even a good GOES grade may not deliver the expected transformer performance.

A simple way to think about it is wood grain. Working along the grain is not the same as working across it. GOES behaves in a similar way, but the difference shows up in magnetic performance.

NGOES: Better When the Field Keeps Moving

Non-oriented electrical steel provides more balanced magnetic properties across the sheet, making it better suited to motors and generators where flux changes direction during operation.

That makes it useful when the magnetic field does not stay fixed.

In motor laminations, the magnetic field rotates through the stator, so the material must respond from different angles rather than one preferred direction.

Core Loss, Direction, and Material Consistency

When buyers compare electrical steel coils, the first number they often check is core loss. That makes sense. Core loss affects heat, efficiency, and long-term energy cost.

But the lowest number on the datasheet is not always the best choice. For GOES and NGOES, direction can change how much of that performance the core actually gets.

GOES performs at its best when the magnetic flux follows the rolling direction. In that direction, it can offer very low core loss. Move away from that direction, though, and the advantage can drop fast.

NGOES is less about one peak value. It usually cannot match GOES at its strongest angle, but its magnetic behavior is more even across different directions. That makes the material easier to evaluate when the flux path is not fixed.

Because electrical steel grades are defined under specific test conditions, loss values should only be compared at the same frequency, flux density, and thickness. A lower number does not mean much if the test conditions or magnetic direction are different.

For buyers sourcing electrical steel coils from HWHG, this point also affects the price directly. HWHG prices electrical steel coils based on magnetic loss performance, not just by grade name or thickness.


After core loss and direction are checked, permeability and saturation can be treated as confirmation points rather than a separate comparison. The question is simple: can the selected grade keep stable magnetic performance at the target flux density, without pushing the core into higher heat or efficiency loss?

Simple Comparison: GOES vs NGOES

Factor	GOES	NGOES
Grain structure	Aligned	More random
Magnetic direction	Strong in one direction	More balanced across directions
Core loss	Very low when flux follows the rolling direction	More stable across different directions
Permeability	Very high in the rolling direction	More uniform
Best fit	Transformer cores	Motors and generators
Processing focus	Direction control	Stamping and lamination flexibility
Typical cost	Higher	Usually lower

How to use this table:

If the design gives the steel one clear magnetic path, GOES is usually worth checking first. If the flux direction changes during operation, NGOES is often the safer first choice.

Where Each Material Makes Sense

GOES is commonly used in transformer cores because the magnetic flux follows a relatively stable path. The strip direction, cutting plan, and core assembly method all affect whether the material can deliver its expected loss performance. For transformer manufacturers, the choice between a cut core and wound core also affects how closely the steel can follow the preferred rolling direction.

Where GOES Makes Sense

NGOES is commonly selected for rotating equipment because it can be stamped into complex laminations without requiring every magnetic path to follow one rolling direction.

For cut cores, wound cores, and laminated transformer cores, the strip direction and cutting plan matter. The material grade is important, but the way the steel is processed and assembled can also affect the final loss performance.

Power transformers
Distribution transformers
High-efficiency toroidal transformers
Shunt reactors
Cut cores, wound cores, and laminated transformer cores

Where NGOES Makes Sense

NGOES is usually used when the magnetic field changes direction during operation. In motor laminations, for example, the magnetic field rotates through the stator. The material has to respond from different angles, not just one preferred direction.

For manufacturers, NGOES can also be easier to process into complex laminations because every magnetic path does not have to be aligned with one rolling direction.

Electric Motors (AC/DC, EV traction motors)
Generators and Alternators
Small Transformers
Lighting Ballasts
Magnetic Switches and Relays

Selection Guide: Start with the Flux Direction

Before comparing grade tables, start with a simpler question: what magnetic direction does your application require from the steel coil?

Use GOES when the material needs strong magnetic performance in one main direction. It is usually selected when low magnetic loss along the rolling direction is the key requirement.

Use NGOES when the application needs more balanced magnetic behavior across the sheet. It is usually a better fit when the steel will be processed into parts where the magnetic direction is not fixed.

Before placing an order, buyers should be clear about the required loss range, thickness, width, and downstream processing needs. HWHG’s pre-shipment magnetic check adds one more layer of control here, helping confirm that the supplied electrical steel coil matches the agreed grade and loss range.


Other Factors to Check Before Ordering

Once the magnetic direction is clear, the next questions are more practical.

Efficiency and cost:

For applications that run for long hours, lower magnetic loss may justify a higher coil price. This is not just about buying a “better” grade. It is about whether the lower loss value can reduce heat and energy loss in the buyer’s final application. For cost-sensitive parts, a more standard NGOES grade may be easier to justify.

Operating frequency:

As frequency rises, lamination thickness becomes more important because thinner sheets can reduce eddy-current loss but require tighter rolling, stamping, and stacking control.

Processing method:

If the steel will be stamped, slit, or cut after purchase, the processing method should be considered early. NGOES is generally easier to use in complex stamped parts. GOES needs more attention to orientation, so the buyer’s cutting layout should keep the rolling direction in mind.

The safer purchase is not simply the coil with the lowest loss number. It is the coil whose loss range, thickness, width, magnetic direction, and downstream processing requirements all match the intended use.

FAQs

Is GOES more expensive than NGOES?

Usually, yes. GOES requires a more controlled manufacturing process to align the grains, so it normally costs more than NGOES. The higher cost can still make sense in transformer cores where lower losses matter over long operating hours.

Can GOES be used in an electric motor to reduce core loss?

In most cases, no. GOES only gives its best low-loss performance in one direction. A motor has a rotating magnetic field, so the material would be forced to work outside its preferred direction for much of the cycle. That can increase loss and heat instead of reducing them.

What is the meaning of different grades of electrical steel?

Electrical steel grades usually describe core-loss limits under defined test conditions, such as frequency and flux density. In many grade systems, a lower number often means lower core loss, but the naming rules vary by standard and supplier. Thickness is also part of the specification and should be checked separately.

Why is silicon added to electrical steel?

Silicon increases the steel’s electrical resistivity. In simple terms, it makes it harder for eddy currents to circulate inside the core, so less energy is wasted as heat.

What are the distinctions between GOES/NGOES and CRGO/CRNGO?

They refer to the same material families. “CR” means cold-rolled. CRGO is cold-rolled grain-oriented electrical steel, and CRNGO is cold-rolled non-grain-oriented electrical steel. In many industry contexts, GOES and CRGO are used for the same type of material, while NGOES and CRNGO are used in the same way.
